Turn one image into many
Every image you upload to Frametile is a base image. When you request it through its delivery URL, you can add transformation parameters to the URL and Frametile generates a brand-new image on the fly. Your original is never changed.
Every picture on this page was generated by Frametile itself from a handful of sample photos, such as pear, fjord and lioness. The caption under each picture is the exact transformation that produced it.
| Concept | What it means | |
|---|---|---|
Base image
|
An image you uploaded to a folder. Transformations never modify it. | |
Transformation
|
One or more parameters in the URL, such as w_300 or e_sepia, that describe the new image.
|
|
Delivery URL
|
The address that returns the transformed image. Use it anywhere an image URL works. | |
API key
|
Your personal key, created when you first sign in. Every request needs it. |
Anatomy of a delivery URL
https://frametile.com/api/:api_key/images/:folder/:image/:transformations
| Part | What it is | Example |
|---|---|---|
:api_key
|
Your personal API key. |
YOUR_API_KEY
|
:folder
|
The folder that holds the base image. |
fruit
|
:image
|
The name of the base image. It is always the last part of the URL. |
pear
|
:transformations
|
Zero or more transformation components, placed before the image name. |
w_300,c_fill
|
Rules
- A parameter is a short name, an underscore and a value:
w_300. - Separate several parameters in one component with commas:
w_300,h_300,c_fill. - Separate components with
/. They are applied in order, left to right. See chaining. - Inside one component, parameters are applied in a fixed order: resize or crop, rotate, effect, flip, opacity, rounded corners, then border.
- Text values, such as overlay text, must be URL-encoded.
- With no transformations, the original file is returned unchanged.
https://frametile.com/api/YOUR_API_KEY/images/fruit/pear
https://frametile.com/api/YOUR_API_KEY/images/fruit/pear/w_300,h_300,c_fill,g_south
https://frametile.com/api/YOUR_API_KEY/images/fruit/pear/e_grayscale/r_40
Resize, crop and scale
Set a size with w_ and h_, then choose how the image should fill that size with a crop mode.
| Parameter | What it does | Example |
|---|---|---|
w_
|
Width in pixels. |
w_300
|
h_
|
Height in pixels. |
h_300
|
ar_
|
Aspect ratio. Give a width or a height and the other is calculated. |
w_300,ar_16:9,c_fill
|
c_
|
Crop mode. See the table below. The default is fit.
|
c_fill
|
g_
|
Gravity: the part of the image to keep or anchor to. |
g_north
|
x_ · y_
|
Offsets in pixels, used with c_crop, c_thumb and overlays.
|
x_20,y_20
|
z_
|
Zoom for c_thumb. A value above 1 keeps less of the image.
|
z_1.5
|
dpr_
|
Multiplies the width and height for high-density screens. |
w_200,dpr_2.0
|
Crop modes
| Mode | What it does | |
|---|---|---|
fit
|
Resizes to fit inside the width and height, keeping the aspect ratio. The result can be smaller than the box in one direction. | |
fill
|
Resizes and crops so the image fills the width and height exactly. | |
pad
|
Resizes to fit, then pads to the exact size. Set the padding colour with b_. b_auto picks a colour from the image edge.
|
|
scale
|
Stretches to the exact width and height and ignores the aspect ratio. With only one of them set, the ratio is kept. | |
crop
|
Cuts out a region of that size without resizing. Choose the region with g_, x_ and y_.
|
|
thumb
|
Crops a region, then resizes it to the exact size. Use z_ to zoom in.
|
|
limit
|
Like fit, but never enlarges an image that is already smaller than the box.
|
|
lfill · lpad
|
Like fill and pad, but return the image unchanged if it is already smaller than the box.
|
Gravity
With c_fill, c_crop and c_thumb, gravity decides which part of the image stays in the frame.
Values: center (default), north, south, east, west, north_east, north_west, south_east and south_west.
g_auto and g_face are accepted, but they behave like g_center. Frametile does not detect faces or the subject of a photo when cropping.Change how an image looks
Add an effect with e_. Some effects take a value after a colon, such as e_blur:600.
| Effect | What it does | Example |
|---|---|---|
e_grayscale
|
Black and white. Also e_blackwhite.
|
e_grayscale
|
e_sepia
|
Warm brown tone. |
e_sepia
|
e_negate
|
Inverts every colour. Also e_invert.
|
e_negate
|
e_blur
|
Gaussian blur. The value divided by 100 is the radius in pixels. The default is a light blur. |
e_blur:600
|
e_sharpen
|
Sharpens fine detail. The change is subtle. |
e_sharpen
|
e_vignette
|
Darkens the corners. The value is the strength in percent. |
e_vignette:60
|
e_pixelate
|
Blocky pixels. The value is the block size. |
e_pixelate:24
|
e_noise
|
Adds grain. The value is the amount. Also e_grain.
|
e_noise:40
|
e_oil_paint
|
A painted look. The change is subtle. |
e_oil_paint
|
e_cartoonify
|
A flat, posterised cartoon look made with image filters. |
e_cartoonify
|
e_brightness · e_contrast · e_saturation
|
Percent change. Positive values increase, negative values decrease. |
e_brightness:35
|
e_tint
|
Blends a colour over the image. The value is the strength in percent (default 50). Set the colour with co_.
|
e_tint:45,co_blue
|
e_outline
|
Draws an outline. The value is the width and co_ sets the colour.
|
e_outline:3,co_white
|
e_shadow
|
Adds a drop shadow. The value is the blur radius. The canvas grows slightly, so the result is a PNG. |
e_shadow
|
e_improve
|
Automatic enhancement. Also e_auto_enhance, e_auto_color, e_auto_contrast and e_auto_brightness.
|
e_improve
|
e_trim
|
Crops away a uniform border. co_ sets the border colour.
|
e_trim
|
e_make_transparent
|
Makes one colour transparent. The value is the tolerance, co_ sets the colour.
|
e_make_transparent:30,co_white
|
e_background_removal
|
Removes the background. See below. |
e_background_removal
|
To stack effects, list them in one component, e_grayscale,e_sepia, or in separate components. They are applied in order.
AI background removal
e_background_removal cuts the subject out of its background and keeps the transparency. It runs a neural-network segmentation model (rembg) on the Frametile server.
If that model is not available on the server, a simpler method based on the colour at the image edges is used. It works best on plain backgrounds.
The result is transparent, so it is returned as a PNG unless you choose another format. The shortcut t_bg-rem does the same thing.
Layer text and images
Add a layer with l_. A layer can be text or another image.
Text overlay
l_text:Font_Size_Weight_Align:Your%20text
| Part | What it is | Example |
|---|---|---|
Font
|
A font family. Bundled fonts include Roboto, Noto Sans, Noto Serif, Noto Sans Mono and Noto Sans CJK JP for Japanese text. Write the name without spaces. |
Roboto
|
Size
|
Font size in pixels. |
72
|
Weight (optional)
|
bold, italic, normal, light, thin, medium, semibold, extrabold or black.
|
bold
|
Align (optional)
|
left, center or right.
|
center
|
Text
|
Your text, URL-encoded. It comes after the second colon. |
Fresh%20Pear
|
co_
|
Text colour. The default is black. |
co_white
|
g_ · x_ · y_
|
Where the text sits. The default gravity for text is south. The offsets move it away from the edge.
|
g_north,y_30
|
w_ · h_ with c_fit
|
Wraps the text inside a box and shrinks it until it fits. Without c_fit, w_ only shrinks the font until the line fits the width.
|
w_400,c_fit
|
Image overlay
l_badge,w_110,g_north_east,x_16,y_16
Use the name of another image you own in Frametile after l_. Then size and place it in the same component.
| Parameter | What it does | Example |
|---|---|---|
w_ · h_
|
Resizes the overlay. With only one of them, the ratio is kept. |
w_110
|
o_
|
Overlay opacity from 0 to 100. |
o_80
|
g_ · x_ · y_
|
Where the overlay sits and how far it is from the edge. |
g_north_east,x_16,y_16
|
e_sepia/l_text:Roboto_72_bold:Fresh. Inside a component that has a layer, only the layer is applied. Output settings such as f_ and q_ next to a layer apply to the whole image.Corners, borders, rotation and opacity
| Parameter | What it does | Example |
|---|---|---|
r_
|
Rounded corners. The value is the radius in pixels. Corners become transparent, so the result is a PNG. |
r_60
|
bo_
|
A border, written as the width in pixels, an underscore and a colour. |
bo_10px_white
|
b_
|
Background colour. It fills the padding of c_pad, and flattens any transparency onto that colour.
|
b_4B5FD6
|
o_
|
Opacity of the whole image from 0 to 100. |
o_50
|
a_
|
Rotation in degrees. The canvas grows to fit and the new corners are transparent. |
a_20
|
fl_horizontal · fl_vertical
|
Mirror the image left to right, or top to bottom. |
fl_horizontal
|
co_
|
A colour used by text overlays and by effects such as e_tint and e_shadow.
|
co_white
|
Colours
Use a colour name such as white or red, or a hex value without the hash: 4B5FD6. The form rgb:4B5FD6 also works.
Choose the format and the quality
| Parameter | What it does | Example |
|---|---|---|
f_
|
Output format: jpg, png, webp, avif or auto.
|
f_webp
|
q_
|
Quality from 1 to 100, or auto (85). It applies to JPEG and WebP output.
|
q_80
|
- With no
f_, the result is a JPEG, or a PNG when the image has transparent areas. f_autoreturns WebP, or PNG when the image has transparent areas.- Pick the format with
f_in the same component as your other parameters:w_480,f_webp,q_80.
What it means for file size
Measured on the sample photo at w_480. Your sizes will depend on your own images.
| Format | File size | Example |
|---|---|---|
JPEG
|
63.6 KB |
f_jpg
|
PNG
|
439.0 KB |
f_png
|
WebP
|
41.3 KB |
f_webp
|
AVIF
|
33.4 KB |
f_avif
|
| JPEG quality | File size | Example |
|---|---|---|
20
|
15.3 KB |
f_jpg,q_20
|
50
|
25.6 KB |
f_jpg,q_50
|
80
|
43.1 KB |
f_jpg,q_80
|
100
|
200.7 KB |
f_jpg,q_100
|
auto
|
50.5 KB |
f_jpg,q_auto
|
Shortcuts for common looks
Write t_ or bl_ followed by a name, for example t_bg-rem. You can mix a name with other parameters: t_sepia,w_300.
| Name | Same as | |
|---|---|---|
bg-rem · bg-removal · bg-remove · bgremoval
|
e_background_removal
|
|
bg-rem-gray
|
e_background_removal, then e_grayscale
|
|
gray · bw
|
e_grayscale
|
|
sepia
|
e_sepia
|
|
cartoon · cartoonify
|
e_cartoonify
|
|
sharpen
|
e_sharpen
|
|
noise
|
e_noise:18
|
|
vignette · outline · shadow
|
e_vignette, e_outline, e_shadow
|
Build an image step by step
Each /-separated component works on the result of the one before it.
https://frametile.com/api/YOUR_API_KEY/images/fruit/pear/c_fill,w_300,h_300/e_sepia/r_40/bo_6px_white
c_fill,w_300,h_300crops to a 300 by 300 square.e_sepiagives it a sepia tone.r_40rounds the corners.bo_6px_whiteadds a white border.
Who can request an image
Every request needs a valid API key, and the key must belong to the owner of the image or of its folder. Generated images are cached by their full URL, so a repeat request is served from storage instead of being generated again. Changing any character in the URL creates a new image.
| Status | Meaning | Common cause |
|---|---|---|
401
|
The API key is not valid. |
A typo in <code>:api_key</code>.
|
403
|
The key is valid but does not own the image or its folder. |
Requesting another user's image.
|
404
|
The base image was not found. |
A wrong folder or image name.
|
400
|
A parameter could not be applied. |
An overlay name that does not exist or that you cannot use.
|
Every parameter at a glance
| Parameter | Purpose | Example |
|---|---|---|
w_ · h_
|
Width and height in pixels. |
w_300,h_300
|
ar_
|
Aspect ratio. |
ar_16:9
|
c_
|
Crop mode: fit, fill, pad, scale, crop, thumb, limit, lfill, lpad. |
c_fill
|
g_
|
Gravity. |
g_south
|
x_ · y_ · z_
|
Offsets and zoom. |
x_20,y_20
|
dpr_
|
Pixel density multiplier. |
dpr_2.0
|
e_
|
An effect, with an optional value after a colon. |
e_blur:600
|
l_
|
A text or image layer. |
l_text:Roboto_72_bold:Fresh
|
co_
|
Colour for text and effects. |
co_white
|
r_
|
Rounded corners in pixels. |
r_60
|
bo_
|
Border: width in pixels and colour. |
bo_10px_white
|
b_
|
Background colour. |
b_white
|
o_
|
Opacity from 0 to 100. |
o_50
|
a_
|
Rotation in degrees. |
a_20
|
fl_
|
Flip: horizontal or vertical. |
fl_horizontal
|
f_
|
Output format. |
f_webp
|
q_
|
Output quality. |
q_80
|
t_ · bl_
|
A named transformation. |
t_bg-rem
|
